| Opening angle | Closing type | Application | Diameter of hinge cup |
|---|---|---|---|
| 110° | Soft close | Face Frame | 35mm |
| Boring distance range | Distance of cup holes centers | Door thickness | Finishing |
| 3-7mm | 45mm | 14-21mm | Nickel plated |
| Height of hinge cup | Material Thickness | Main material | |
| 11.5mm | 0.8 - 1.2 - 1.2mm | Cold-rolled steel |
| Product & Sales Description | SKU |
|---|---|
| Clip-On Hinge, Regular, Full Overlay, Screw On | 328-1AF |
| Clip-On Hinge, Regular, Full Overlay, With Dowel | 328-1BF |
| Clip-On Hinge Soft Close, Full Overlay, Screw On | 328-2AF |
| Clip-On Hinge Soft Close, Half Overlay, Screw On | 328-2AH |
| Clip-On Hinge Soft Close, Full Overlay, With Dowel | 328-2BF |
| Clip-On Hinge Soft Close, Half Overlay, With Dowel | 328-2BH |
| Clip-On Hinge Soft Close, Inset, Screw On | 328-2AIN |
| Clip-On Hinge Soft Close, Inset, With Dowel | 328-2BIN |
| 0 mm Mounting Plate for clip-on Hinge | 328-00P |
| 3 mm Mounting Plate for clip-on Hinge | 328-03P |
| 6 mm Mounting Plate for clip-on Hinge | 328-06P |
| Face Frame Hinge -Clip On, Cam Adjustable, 0 MM, Plate - Metal | 328M-00P |
| Face Frame Hinge -Clip On, Cam Adjustable, 2 MM, Plate - Metal | 328M-02P |
| Face Frame Hinge -Clip On, Cam Adjustable, 3 MM, Plate - Metal | 328M-03P |
| Frameless Hinge - 328 Series: Clip On, 3D Adj. 0 MM Plate | 328-EP00 |
| Frameless Hinge - 328 Series: Clip On, 3D Adj. 9 MM Plate | 328-EP09 |
| Frameless Hinge - 328 Series: Clip On, 3D Adj. 18 MM Plate | 328-EP18 |
